British Standards Underfloor Heating CAD Design
Underfloor heating systems only perform as intended when they are properly designed. Our British Standards UFH CAD design service provides professional, calculation-led layouts for trade projects where compliance, performance and reliability matter.
All UFH designs are completed in-house, independent of any manufacturer or product, and suitable for both domestic and commercial applications.
Why British Standards Matter in UFH Design
UFH design is not just about layout — it’s about ensuring the system can meet the demands of the space it serves.
Designs that are not properly calculated can lead to:
- uneven heating
- insufficient output
- overheating of floor finishes
- costly remedial work
By designing in accordance with BS EN1264 and CIBSE Standards, we ensure systems are engineered to perform as expected — not based on assumptions or generic layouts.
Calculation-Led UFH Design (Not Rule of Thumb)
Our UFH CAD designs are based on:
- room-by-room heat requirements
- system output calculations
- floor construction and usage
- zoning and control strategies
We don’t publish calculation methods or formulas.
Designs are delivered as a professional service, not a DIY guide.
This protects the integrity of the design and ensures consistent, repeatable results.
Independent of Any UFH System or Supplier
We do not supply underfloor heating products and are not tied to any manufacturer.
This means:
- designs are not influenced by product margins
- no supplier lock-in
- freedom to specify the most appropriate system for the project
Our focus is on design quality and compliance, not product sales.
Suitable for Domestic & Commercial Projects
Our British Standards UFH designs are suitable for:
- residential developments
- commercial floors
- mixed-use buildings
- new builds and retrofits
This makes them ideal for professional installers, contractors and screeding companies working on a wide range of projects.
Who This Service Is For
This service is provided exclusively to trade professionals, including:
- UFH System Suppliers
- UFH installers
- Screeding companies
- Contractors and developers
- UFH suppliers requiring independent designs
It is not suitable for homeowners or self-build projects.
